Imperial Single Row-1

These three-bolt bracket flanged ball bearing units consist of a plug-in bearing with an extended inner ring and are locked to the shaft by an adapter sleeve, allowing the bearing to run at higher speeds and run more smoothly in the following applications Rotation is constant or alternating. The bearings are housed in a cast iron housing that can be bolted to the machine wall or frame. Adapter sleeves are not included with the unit and should be ordered separately.

SKF Number	Principal dimensions					Limiting speed	Limiting temperature	Included products
	d[mm]	A[mm]	J[mm]	L[mm]	T[mm]	[r/min]	Tmax.[°C]	Bearing
FY 3/4 TF/VA201	19.05	29.5	63.5	86	37.3	130	250	YAR 204-012-2F/VA201
FY 3/4 TF/VA228	19.05	29.5	63.5	86	37.3	260	350	YAR 204-012-2F/VA228
FY 20 TF/VA201	20	29.5	63.5	86	37.3	130	250	YAR 204-2F/VA201
FY 20 TF/VA228	20	29.5	63.5	86	37.3	260	350	YAR 204-2F/VA228
FY 25 TF/VA201	25	30	70	95	38.8	110	250	YAR 205-2F/VA201
FY 25 TF/VA228	25	30	70	95	38.8	230	350	YAR 205-2F/VA228
FY 1. TF/VA201	25.4	30	70	95	38.8	110	250	YAR 205-100-2F/VA201
FY 1. TF/VA228	25.4	30	70	95	38.8	230	350	YAR 205-100-2F/VA228
FY 30 TF/VA201	30	32.5	82.5	108	42.2	90	250	YAR 206-2F/VA201
FY 30 TF/VA228	30	32.5	82.5	108	42.2	190	350	YAR 206-2F/VA228
FY 1.3/16 TF/VA201	30.163	32.5	82.5	108	42.2	90	250	YAR 206-103-2F/VA201
FY 1.3/16 TF/VA228	30.163	32.5	82.5	108	42.2	190	350	YAR 206-103-2F/VA228
FY 1.1/4 TF/VA201	31.75	34.5	92	118	46.4	80	250	YAR 207-104-2F/VA201
FY 1.1/4 TF/VA228	31.75	34.5	92	118	46.4	160	350	YAR 207-104-2F/VA228
FY 35 TF/VA201	35	34.5	92	118	46.4	80	250	YAR 207-2F/VA201
FY 35 TF/VA228	35	34.5	92	118	46.4	160	350	YAR 207-2F/VA228
FY 1.7/16 TF/VA201	36.512	34.5	92	118	46.4	80	250	YAR 207-107-2F/VA201
FY 1.7/16 TF/VA228	36.512	34.5	92	118	46.4	160	350	YAR 207-107-2F/VA228
FY 1.1/2 TF/VA201	38.1	38.5	101.5	130	54.2	70	250	YAR 208-108-2F/VA201
FY 1.1/2 TF/VA228	38.1	38.5	101.5	130	54.2	150	350	YAR 208-108-2F/VA228
FY 40 TF/VA201	40	38.5	101.5	130	54.2	70	250	YAR 208-2F/VA201
FY 40 TF/VA228	40	38.5	101.5	130	54.2	150	350	YAR 208-2F/VA228
FY 1.11/16 TF/VA201	42.862	39	105	137	54.2	60	250	YAR 209-111-2F/VA201
FY 1.11/16 TF/VA228	42.862	39	105	137	54.2	130	350	YAR 209-111-2F/VA228
FY 1.3/4 TF/VA201	44.45	39	105	137	54.2	60	250	YAR 209-112-2F/VA201
FY 1.3/4 TF/VA228	44.45	39	105	137	54.2	130	350	YAR 209-112-2F/VA228
FY 45 TF/VA201	45	39	105	137	54.2	60	250	YAR 209-2F/VA201
FY 45 TF/VA228	45	39	105	137	54.2	130	350	YAR 209-2F/VA228
FY 1.15/16 TF/VA201	49.213	43	111	143	60.6	60	250	YAR 210-115-2F/VA201
FY 1.15/16 TF/VA228	49.213	43	111	143	60.6	120	350	YAR 210-115-2F/VA228
FY 50 TF/VA201	50	43	111	143	60.6	60	250	YAR 210-2F/VA201
FY 50 TF/VA228	50	43	111	143	60.6	120	350	YAR 210-2F/VA228
FY 2. TF/VA201	50.8	47.5	130	162	64.4	50	250	YAR 211-200-2F/VA201
FY 2. TF/VA228	50.8	47.5	130	162	64.4	110	350	YAR 211-200-2F/VA228
FY 55 TF/VA201	55	47.5	130	162	64.4	50	250	YAR 211-2F/VA201
FY 55 TF/VA228	55	47.5	130	162	64.4	110	350	YAR 211-2F/VA228
FY 2.3/16 TF/VA201	55.562	47.5	130	162	64.4	50	250	YAR 211-203-2F/VA201
FY 2.3/16 TF/VA228	55.562	47.5	130	162	64.4	110	350	YAR 211-203-2F/VA228
FY 60 TF/VA201	60	52	143	175	73.7	50	250	YAR 212-2F/VA201
FY 60 TF/VA228	60	52	143	175	73.7	100	350	YAR 212-2F/VA228
FY 2.7/16 TF/VA201	61.913	52	143	175	73.7	50	250	YAR 212-207-2F/VA201
FY 2.7/16 TF/VA228	61.913	52	143	175	73.7	100	350	YAR 212-207-2F/VA228
