Large Angular Contact Ball Bearing - Open, Double Row
Two types of contact angles can be selected according to the magnitude of the axial load and moment load.
Similar to single-row deep groove ball bearings, with a seal (2NS) and shield (ZZ) attached.
Can be used on Blower, High-speed vacuum pump receiver, Supercharger and Two-wheeled vehicle transmission
| Bearing Number | d mm | D mm | Bmm |
| 5205 E | 25 | 52 | 20.6 |
| 5206 E | 30 | 62 | 23.8 |
| 5207 E | 35 | 72 | 27.0 |
| 5208 E | 40 | 80 | 30.2 |
| 5209 E | 45 | 85 | 30.2 |
| 5210 E | 50 | 90 | 30.2 |
| 5211 E | 55 | 100 | 33.3 |
| 5212 E | 60 | 110 | 36.5 |
| 5213 E | 65 | 120 | 38.1 |
| 5214 E | 70 | 125 | 39.7 |
| 5215 E | 75 | 130 | 41.3 |
| 5216 E | 80 | 140 | 44.4 |
| 5217 E | 85 | 150 | 49.2 |
| 5218 E | 90 | 160 | 52.4 |
| 5305 E | 25 | 62 | 25.4 |
| 5306 E | 30 | 72 | 30.2 |
| 5307 E | 35 | 80 | 34.9 |
| 5308 E | 40 | 90 | 36.5 |
| 5309 E | 45 | 100 | 39.7 |
| 5310 E | 50 | 110 | 44.4 |
| 5311 E | 55 | 120 | 49.2 |
| 5312 E | 60 | 130 | 54.0 |
| 5313 E | 65 | 140 | 58.7 |
| 5314 E | 70 | 150 | 63.5 |
| 5315 E | 75 | 160 | 68.3 |
| 5316 E | 80 | 170 | 68.3 |
