Imperial Single Row-1

Deep groove ball suffix meaning:

CN: Common Group Radial Clearance; usually only used in combination with the following letters to denote narrower or offset clearance ranges

H: Reduced clearance range, equivalent to the upper half of the original clearance range

L: Reduced clearance range, equivalent to the lower half of the original clearance range

P: The offset clearance range, which is equivalent to the composition of the upper half of the original clearance range and the lower half of the next set of clearance ranges. The above letters also apply to the meanings corresponding to the following clearance groups: C2, C3, C4, and C5, such as C2

C2: Radial clearance is smaller than ordinary group

C3: Radial clearance is larger than ordinary group

C4: Radial clearance is greater than C3

C5: Radial clearance is greater than C4

DB: Two single row deep groove ball bearings paired back-to-back

DF: Two single row deep groove ball bearings mated face to face

DT: Two single row deep groove ball bearings paired in tandem

Bearing Number			d mm inch		D mm inch		B mm inch
8501	87501	88501	12	0.4724	32	1.2598	12.7	0.5
8013	87013	88013	13	0.5118	32	1.2598	12.7	0.5
8014	87014	88014	14	0.5512	35	1.378	12.7	0.5
8502	87502	88502	15	0.5906	35	1.378	12.7	0.5
8016	87016	88016	16	0.6299	35	1.378	12.7	0.5
8602	88602	88602	15	0.5906	42	1.6535	15	0.5906
8503	88503	88503	17	0.6693	40	1.5748	14.288	0.5625
8603	88603	88603	17	0.6693	47	1.8504	16	0.6299
8504	88504	88504	20	0.7874	47	1.8504	15.875	0.625
8604	88604	88604	20	0.7874	52	2.0472	19	0.748
8505	88505	88505	25	0.9843	52	2.0472	15.875	0.625
8605	88605	88605	25	0.9843	62	2.4409	21	0.8268
8506	88506	88506	30	1.1811	62	2.4409	20	0.7874
8606	88606	88606	30	1.1811	72	2.8346	23	0.9055
8507	88507	88507	35	1.378	72	2.8346	21	0.8268
8607	88607	88607	35	1.378	80	3.1496	25	0.9843
8508	88508	88508	40	1.5748	80	2.1496	24	0.9449
8608	88608	88608	40	1.5748	90	3.5433	27	1.063
8509	88509	88509	45	1.7717	85	3.6465	24	0.9449
8609	88609	88609	45	1.7717	100	3.937	30	1.1811
8510	88510	88510	50	1.9615	90	3.5433	26	1.0236
8511	88511	88511	55	2.5614	100	3.937	27	1.063
